IMDK Finger Pulse Oximeter

IMDK Finger Pulse Oximeter

The IMDK finger pulse oximeter uses the latest oxygen sensor technology to accurately determine the level of oxygen in blood (SpO2) in 8 seconds. The measurement range is 70% - 99% with ±2% accuracy and ±1% of resolution. IMDK finger pulse oximeter fits all finger sizes and provides 6,000 spot checks. It is easy to operate with only one button and comes with a lanyard for easy carrying. An alarm beeps to indicate oxygen level and heart rate. To save power, it automatically powers off after 8 seconds.

Sleep Monitor

Perfusion Index (PI) will improve the reliability of the readings dramatically. The PI conveniently informs you of the strength of your pulse. The sleep monitoring function can keep the data record for 8 hours and it will start analyze after monitoring for more than 2 hours.

Key Features:

• OLED display for easy read
• Up to 8 hours of sleep monitoring
• Low power consumption
• Simultaneous display for testing value and bar graph
• Auto power off: 8 seconds automatic shutdown
• Light weight: only 2.2 oz with 2 AAA alkaline batteries (batteries not included)
• Fits every finger size
• 6,000 spot checks
• FDA approved

Multi-Direction Display

Multidirectional display: 4 directions, 6 modes to allow you view your results in any direction.

Alarm Function

The alarm will release warning sounds once the measured values go beyond the setting which gives you immediate response.

Parameters

• SpO2

Measurement range: 70% - 99%
Resolution: ±1%
Accuracy: ±2% (70%-99%), unspecified (<70%)

• Pulse Rate
  Measurement range: 30 BPM - 240 BPM
  Resolution: ±1%
  Accuracy: ±2bpm or +2% (select larger)
  Low Perfusion ?0.4%
• Power: 2 AAA 1.5 V alkaline batteries (not included in package)
  Supply voltage: 2.6-3.6V
• Air Pressure: 70kPA - 106 kPa
• Working Current: ? 30 mA
